Maintenance-free due to long-life ultracapacitors
Low wiring effort due to the integration of the energy storage device
Microcontroller-supported charging and discharging of the ultracapacitors
Mains monitoring via potential-free contact and LED
Vibration-proof wiring due to spring-loaded technology
Wide temperature range -40 °C to 60 °C
| energy | 5,8 kJ |
| input voltage | 24 V (SELV/PELV) |
| decoupled | 23,9 - 27 V DC ±0 % |
| not decoupled | 23,4 - 27 V DC ±0 % |
| rated output voltage | 24 V DC |
| output voltage in back-up mode | 23,2 V DC ±2 % |
| nominal output current | 10 A |
| dimensions (h x w x d) | 172,4 mm x 116 mm x 143 mm |
| weight | 1,8 kg |
